The Rx Fill API provides the ability to submit new prescription fill requests and to retrieve status messages for previously sent prescription fill requests.

Submit Fill Request

See RxFill API reference for request message fields.

Server

Only https connections are accepted.

REQUEST TYPE	ENDPOINT
POST (Test)	uat.apiservices.azure-api.net/rx/v2/fillrequest
POST (Prod)	centralfill.healthdyne.com/rxfill/fillRequest

Header

Key	Value
Accept	application/json
Content-Type	application/json
HealthDyne-Subscription-Key	Provided by HealthDyne

📘
Depending on the business model, an additional element may be required in the header to help identify and label the prescription correctly.

RxFill Response codes

The below table lists the potential response codes that can be received in response to a POST request.

Code	Description
200	Message Received
400	Bad Request
409	Message already exists (based on MessageId)
500	Internal Server Error

Sample RxFill

{
	"messageid": "z79v4c1g-1w09-4514-b4fc-1286reae0egb07-v2-12",
	"ordernumber": "TST1234RVVL-v2-12",
	"pharmacy": {
		"name": "HEALTHDYNE PHARMACY",
		"address": {
			"address1": "500 EAGLES LANDING DRIVE",
			"city": "LAKELAND",
			"phone": "",
			"state": "FL",
			"zip": "33801"
		},
		"npi": "1740363274"
	},
	"patient": {
		"id": "1569928",
		"accountNumber": "1569928",
		"firstName": "FIRSTNAME",
		"lastName": "LASTNAME",
		"preferredLanguage": "ENG"
	},
	"prescriptions": [
		{
			"rxNumber": "645917",
			"drug": {
				"ndc": "00002143380",
				"manufacturer": "GRIFOLS USA",
				"name": "MARPLAN TAB 10MG",
				"strength": "1000",
        "dispenseDrugName": "MARPLAN TAB 10MG",
				"writtenDrugName": "",
       	"unitOfMeasure": "ML"
			},
			"quantity": 1,
			"refill": {
				"fillNumber": 13,
				"nextRefillDate": "2021-01-12T00:00:03",
				"refillsPrescribed": 13,
				"refillsDispensed": 13,
				"refillsRemaining": 0
			},
			"prescriber": {
				"deaNumber": "1235",
				"firstName": "John",
				"lastName": "Doe"
			},
			"writtenDate": "2021-02-02T12:28:59",
			"dispensedDate": "2020-12-15T00:00:03",
			"expirationDate": "2021-12-14T00:00:03",
			"unitprice": 1.02,
			"copayamount": 1.03,
			"referencedata": [],
			"pharmacist": {
				"initials": null,
				"FirstName": "Test",
				"LastName": "TestLname"
			},
			"vialLabel": {
				"sig": "TAKE 1 TABLET BY MOUTH DAILY",
				"additionalSig": null,
				"braille": false,
				"largePrint": false,
				"audioLabel": false
			}
		}
	],
	"shipping": {
		"shippingCode": "UPS 1D",
		"signatureRequired": false,
		"saturdayDelivery": false,
		"address": {
			"name": "John Robertson",
			"address1": "407 N CAROLINE ST ",
			"address2": "",
			"city": "BALTIMORE",
			"phone": "7743866854",
			"state": "MD",
			"zip": "21231",
			"clinicId": null
		},
		"deliveryInstructions": "",
		"holdAddress": {
			"name": "",
			"address1": "",
			"address2": "",
			"city": "",
			"phone": "",
			"state": "",
			"zip": ""
		},
		"notificationEmail": ""
	},
	"CustomData": []
}

Cancel a Fill Request:

The Cancel Request API enables client systems to submit a cancellation request for an existing order. This API supports order-level cancellation when an order is no longer needed or was submitted in error.An order can only be canceled if it is in a cancelable state. If the order does not meet the criteria for cancelation (e.g., already processed or dispensed), the API will return an appropriate response indicating that the cancelation cannot be performed.

Server

Only https connections are accepted.

REQUEST TYPE	ENDPOINT
POST (Test)	uat-apiservices.azure-api.net/v2/fillrequest/cancel
POST (Prod)	centralfill.healthdyne.com/fillrequest/cancel

Sample Cancel Fill Request

{
 "messageid": "1w09-4514-b4fc-1286reae0egb07-v2-12",
  "ordernumber": "TST1234RVVL-v2-12",
  "CancelReason": "Order submitted in error"
}
